Реверс інжиніринг та виготовлення складної тривимірної поверхні

Abstract

UA: В роботі розглянуто методи, що визначають можливості створення складних поверхонь за допомогою інформаційних технологій. Сучасні тенденції розвитку різних галузей промисловості стимулюють розробку високоефективних і конкурентних видів техніки і технологій, які забезпечать жорсткі вимоги к якості та експлуатаційним властивостям виробів при економії матеріальних та енергетичних ресурсів, витрати на робочу силу, зниження собівартості виробництва, що є актуальними для машинобудування. EN: Methods that determine possibilities of creation of difficult surfaces by means of information technologies are in-process considered. Modern progress of different industries of industry trends stimulate development of high-efficiency and competition types of technique and technologies, that will provide hard requirements to quality and operating properties of wares at the economy of material and power resources, expense, on labour force, a decline is a production cost that is actual for an engineer [1, 5]. An aim of technologist is in that, to project a technological process with the least of transitions, high coefficient of the use of material, exact geometrical parameters. In addition, the made detail must answer the indicated operating descriptions. Development of technique on the modern stage is characterized deployment of information technologies in all her areas. Special attention is deserved by the difficult-shaped by volume wares, that are characterized not only complication of relief of separate elements of these wares but also presence most various in a due form and to the sizes of internal channels, transitions, connections etc. Making of such wares is presently based on the use of enormous amount of the software of different firms, sent to the decision of tasks arising up at making of difficult-profile wares. After working off the construction of good at his raising on a production depending on the volume of material, construction, form and sizes of good, the tasks of choice of method of receipt of purveyances and good decide on the whole, developments and making of technological equipment, program (choice of software) development for the receipt of purveyances and wares [2, 3, 4]. In this connection choice of effective software product, providing the production of one or another shaped good, is an important task.
